9-port fast industrial switch

Overview

The SmartByteLT-IS3009F-1FX8TX series are unmanaged industrial grade Ethernet switches with 8-port 10/100-TX RJ45 and 1-port 100Base-FX fiber optical interface. They are featuring with port isolation, flow control, QoS(1-2 ports) and broadcast storm restrain function, which all can be configured by the Dip switch on the top panel.

LT-IS3009F-1FX8TX series are also high cost-effective easy-to-use devices, which provide essential industrial Ethernet networking function, such as wide range power input 12-58VDC, redundant power design with polarity reverse/over-voltage protection, robust IP40 fan-less housing with Din-rail installation, wide operation temperature from -40°C to 75°C as well as high-level EMI/EMC capability and so on. It is the best choice for heavy industrial factory,transportation, oil & gas, chemical,IP Surveillance and processing automation area where environmental conditions exceed commercial product specifications.

Features

➢ 8*10/100Base-TX RJ45 ports, 1*100Base-FX SFP(/SC/ST/FC optional) fiber port

➢ DC12~58V input, redundant powersupply with polarity reverse/over-voltage protection

➢ Dip switch function: 1.Port isolation; 2. Flow control; 3. QoS; 4. Broadcast storm restrain

➢ Support 9K Bytes Jumbo frame

➢ Support4KV surge protection and ESD: Air-15kV, Contact-8kV Protection

➢ IP40 fan-less andDin-rail hardware design

➢ Operation temperature:-40 ℃ ~+75℃

Model No.	LT-IS3009F-1FX8TX
Interface	Fiber port		Copper RJ45 ports
	1		8
Ethernet	810/100Base-TX RJ45 1100Base-FX SFP/SC/ST/FCfiber port
Standard	IEEE 802.310Base-TEthernet IEEE 802.3u Fast Ethernet IEEE 802.3x Full-Duplex Flow Control IEEE 802.3az Energy Efficient Ethernet
Dip Switch	1. Port Isolation 2. Flow control 3. QoS(1-2 ports） 4. Broadcast storm restrain
LED Indicators	P(Power indicator)Green	Off: the device is power off or failed
		On: the device power on is normal
	S(System indicator) Red	Off:thechip is normal
		On:the chip read/write is unnormal
	1-8(Copper ports)	Green indicators		Yellow indicators
		Off: ports link down		Off:port speed is 10M
		On: ports link up		On: port speed is 100M
		Blinking:data on TX/RX
	9( Fiber port)Green	Off: ports link down
		On: ports link up
		Blinking:data on TX/RX
Power parameters
Input voltage	12-58VDC, redundant power input
Input current	0.5A Max
Total power consumption	Full loading ≤5W
Connector	Removable 4-pin terminal block
Reverse polarity protection	Support
Over-voltage protection	Support
Switching features
Switching capacity	1.8G
Packet forwarding rate	2.67 Mpps
MAC address table	2K
VLAN	2K
Buffer	2Kbits
Forwarding delay	<100us
Jumbo Frame	Support 9Kbytes
MDX/MIDX	Support
Watchdog	Support
Network Topology
Star topology	Support
Bus topology	Support
Tree Topology	Support
Mechanical structure
Case protection	IP40
Installation method	Din-rail
Dimension(WDH)mm	4898130mm
Weight	0.68 kg
Operating environment
Operating temperature	-40℃~+75℃
Storage/transportation temperature	-40℃~+85℃
Relative humidity	5%~95%（non-condensing）
Industrial Standard	Surge protection of power: IEC 61000-4-5 Level 3 (4KV/2KV）（8/20us)
	Surge protection of Ethernet ports: IEC 61000-4-5 Level 3 (4KV/2KV）（10/700us)
	DIP: IEC 61000-4-11 Level 3（10V）
	ESD: IEC 61000-4-2 Level 4（8K/15K）
	Shock：IEC 60068-2-27
	Free fall：IEC 60068-2-32
	Vibration：IEC 60068-2-6
Certification	CCC/CE/FCC/RoHS
Warranty	5 years

LT-IS3009F-1FX8TX datasheet

Model	Description
LT-IS3009F-1FX8TX	10/100Base-TX to 100Base-FX unmanaged industrial Ethernet switch with 810/100Base-TX RJ45 ports and 1100Base-FXSFP slot,DC12-58V input, redundant dual power supply, Din-rail installation.Fiber port transmission distance depending on the SFP module; Operation temperature: -40℃～+75℃
LT-IS3009F-1FX8TX-SC	10/100Base-TX to 100Base-FX unmanaged industrial Ethernet switch with 810/100Base-TX RJ45 ports and 1100Base-FXSC port,DC12-58V input, redundant dual power supply, Din-rail installation; Multi-mode/Single mode/ dual fiber/single fiber, 550m -100KM optional; Operation temperature: -40℃～+75℃
LT-IS3009F-1FX8TX-FC	10/100Base-TX to 100Base-FX unmanaged industrial Ethernet switch with 810/100Base-TX RJ45 ports and 1100Base-FX FC port,DC12-58V input, redundant dual power supply, Din-rail installation; Multi-mode/Single mode/ dual fiber/single fiber, 550m -100KM optional; Operation temperature: -40℃～+75℃
LT-IS3009F-1FX8TX-ST	10/100Base-TX to 100Base-FX unmanaged industrial Ethernet switch with 810/100Base-TX RJ45 ports and 1100Base-FXST port,DC12-58V input, redundant dual power supply, Din-rail installation; Multi-mode/Single mode/ dual fiber/single fiber, 550m -100KM optional; Operation temperature: -40℃～+75℃
